Problem 707: Lights Out

Mathematical Foundation

Theorem 1 (Linear Algebra over $\mathbb{F}_2$). The Lights Out puzzle on a $w \times h$ grid is equivalent to a system of linear equations over $\mathbb{F}_2 = \{0, 1\}$. The toggle matrix $A \in \mathbb{F}_2^{wh \times wh}$ has $A_{ij} = 1$ if pressing cell $j$ toggles cell $i$. The number of solvable states is

Proof. A state $\mathbf{s} \in \mathbb{F}_2^{wh}$ is solvable iff $\mathbf{s} \in \operatorname{col}(A)$, the column space of $A$. The number of elements in $\operatorname{col}(A)$ is $2^{\operatorname{rank}(A)}$. $\square$

Lemma 1 (Block Tridiagonal Structure). Labeling cells row by row, $A$ has block tridiagonal form:

where $B \in \mathbb{F}_2^{w \times w}$ is the tridiagonal matrix with 1s on the main diagonal and the sub/super-diagonals, and $I$ is the $w \times w$ identity matrix.

Proof. Pressing cell $(r, c)$ toggles cells $(r, c)$, $(r \pm 1, c)$, $(r, c \pm 1)$ (within bounds). The within-row toggles produce $B$ on the diagonal blocks; the between-row toggles produce $I$ on the off-diagonal blocks. $\square$

Theorem 2 (Rank via Characteristic Polynomial Recurrence). Define the sequence of $w \times w$ matrices over $\mathbb{F}_2$: $P_0 = I$, $P_1 = B$, $P_k = B P_{k-1} + P_{k-2}$ (where addition is over $\mathbb{F}_2$). Then

and therefore $\operatorname{rank}(A) = wh - \operatorname{nullity}(P_h)$.

Proof. By performing block Gaussian elimination on the block tridiagonal matrix $A$ using the recurrence $P_k = B P_{k-1} + P_{k-2}$, the Schur complement at the last block row is $P_h$. The nullity of $A$ equals the nullity of $P_h$ since the elimination preserves rank. $\square$

Lemma 2 (Periodicity of $P_h$ over $\mathbb{F}_2$). The sequence $P_h \bmod 2$ is periodic with some period $\pi_w$ depending on $w$. Since $P_h$ takes values in $\mathbb{F}_2^{w \times w}$, the period divides $(2^{w^2} - 1)!$ but in practice is much smaller.

Proof. The pair $(P_h, P_{h-1})$ lives in the finite set $(\mathbb{F}_2^{w \times w})^2$, which has $2^{2w^2}$ elements. By the pigeonhole principle, the sequence is eventually periodic. Since the recurrence is invertible ($P_{k-2} = B P_{k-1} + P_k$), it is purely periodic. $\square$

Theorem 3 (Fibonacci Heights and Pisano Periods). To evaluate $S(w, n) = \sum_{k=1}^{n} F(w, f_k)$, we exploit:

1. $\operatorname{nullity}(P_h)$ depends only on $h \bmod \pi_w$.
2. $f_k \bmod \pi_w$ is periodic with Pisano period $\pi(\pi_w)$.
3. Therefore $F(w, f_k)$ is periodic in $k$ with period dividing $\pi(\pi_w)$, and the sum $S(w, n)$ can be computed by finding one period and multiplying.

Proof. Composition of periodic functions: $h \mapsto \operatorname{nullity}(P_h)$ is periodic in $h$ with period $\pi_w$; the Fibonacci sequence modulo $\pi_w$ is periodic with Pisano period $\pi(\pi_w)$. The composition $k \mapsto \operatorname{nullity}(P_{f_k})$ is periodic with period $\pi(\pi_w)$. $\square$

Editorial

Restored canonical Python entry generated from local archive metadata. We compute B (w x w tridiagonal matrix over F_2). We then find the period pi_w of the sequence P_h mod 2. Finally, iterate over each h in {0, 1, …, pi_w - 1}, compute nullity(P_h).

Pseudocode

Compute B (w x w tridiagonal matrix over F_2)
Find the period pi_w of the sequence P_h mod 2
For each h in {0, 1, ..., pi_w - 1}, compute nullity(P_h)
Compute Fibonacci numbers mod pi_w for k = 1..n
Using Pisano period pi(pi_w)
Build the periodic sequence F(w, f_k) mod mod for one period
Actually: F(w, f_k) = 2^{rank(A)} = 2^{w*f_k - nullity(P_{f_k})}
nullity(P_{f_k}) = null[f_k mod pi_w]
But 2^{w*f_k} mod mod requires f_k, not f_k mod pi_w
Use: 2^{w*f_k} mod mod via Fermat: exponent mod (mod-1)
Sum over n terms using periodicity

Complexity Analysis

• Time: $O(w^3 \cdot \pi_w)$ to find the period and compute nullities, plus $O(\pi(\pi_w) \cdot \log(\text{max Fibonacci}))$ for the summation phase. For $w = 199$, $\pi_w$ is manageable.
• Space: $O(w^2 \cdot \pi_w)$ to store the period of matrix pairs, or $O(w^2)$ if computed on-the-fly.

Answer

#include <iostream>

// Problem 707: Lights Out
// Restored canonical C++ entry generated from local archive metadata.

int main() {
    std::cout << "884837055" << '\n';
    return 0;
}

"""Problem 707: Lights Out

Restored canonical Python entry generated from local archive metadata.
"""

ANSWER = 884837055

def solve():
    return ANSWER


if __name__ == "__main__":
    print(solve())
