Problem 300: Protein Folding

Mathematical Foundation

Definition. A self-avoiding walk (SAW) of length $n-1$ on $\mathbb{Z}^2$ is an injective sequence of lattice points $(v_0, v_1, \ldots, v_{n-1})$ where each $|v_{i+1} - v_i|_1 = 1$ (adjacent on the lattice).

Definition. The contact topology of a SAW is the set $\mathcal{C} = \{(i, j) : |i - j| > 1,\; |v_i - v_j|_1 = 1\}$ of non-consecutive adjacent pairs.

Theorem 1 (Decomposition of Contacts). The total H-H contacts for protein $p = (p_0, \ldots, p_{n-1})$ under walk $w$ equals

where $\text{consec}(p) = |\{i : p_i = H \text{ and } p_{i+1} = H\}|$ depends only on $p$, and $\text{non-consec}(p, w) = |\{(i,j) \in \mathcal{C}(w) : p_i = H \text{ and } p_j = H\}|$ depends on both $p$ and $w$.

Proof. Consecutive residues ($|i - j| = 1$) are always lattice-adjacent in any SAW, so their H-H contacts are determined solely by the protein string. Non-consecutive contacts depend on the walk geometry. $\square$

Theorem 2 (Optimality via Topology Enumeration). The optimal contact count for protein $p$ is

where $\mathcal{T}$ is the set of all realizable contact topologies for SAWs of length $n - 1$.

Proof. Since $\text{consec}(p)$ is constant across all walks, maximizing total contacts is equivalent to maximizing non-consecutive contacts. The non-consecutive contacts depend only on the contact topology $\mathcal{C}(w)$, so it suffices to enumerate all distinct topologies rather than all walks. $\square$

Lemma 1 (Bitmask Evaluation). Representing protein $p$ as a bitmask $B \in \{0, 1\}^n$ (where bit $i = 0$ means $p_i = H$ and bit $i = 1$ means $p_i = P$), the contact pair $(i, j)$ contributes iff $(B \mathbin{\&} M_{ij}) = 0$ where $M_{ij} = (1 \ll i) \mid (1 \ll j)$.

Proof. We have $p_i = H$ iff bit $i$ of $B$ is 0, and $p_j = H$ iff bit $j$ is 0. Thus both are H iff $B$ has 0 in positions $i$ and $j$, i.e., $(B \mathbin{\&} M_{ij}) = 0$. $\square$

Lemma 2 (Symmetry Reduction for SAWs). By the 4-fold rotational symmetry and 2-fold reflective symmetry of the square lattice (dihedral group $D_4$), fixing the first step to go rightward reduces the SAW enumeration by a factor of 4. Mirror-image walks produce the same contact topology, further reducing by a factor of 2 in many cases.

Proof. Under rotation by $90°$, a SAW $w$ maps to $w'$ with the same contact topology (since adjacency on $\mathbb{Z}^2$ is rotation-invariant). Fixing the first step eliminates 4 equivalent rotations. Reflection about the $x$-axis also preserves contact topology, though some walks are self-mirror-symmetric and must be handled carefully. $\square$

Theorem 3 (Exact Rationality). The average optimal contact count $E[\text{opt}(p)]$ over all $2^n$ proteins is a rational number with denominator dividing $2^n$.

Proof. Each protein is equally likely with probability $2^{-n}$, and each $\text{opt}(p)$ is a non-negative integer. Thus $E[\text{opt}(p)] = \frac{1}{2^n} \sum_{p} \text{opt}(p) \in \frac{1}{2^n}\mathbb{Z}$. $\square$

Editorial

For each of 2^15 protein strings of length 15 (H/P), find the OPTIMAL (maximum) number of H-H contacts over all self-avoiding walks on 2D lattice. Average the optima. H-H contact: two H residues at lattice-adjacent positions. This includes both consecutive (always adjacent in any walk) and non-consecutive pairs (walk-dependent). Algorithm: 1. Enumerate all SAWs of length 15 (14 steps). 2. For each SAW, find non-consecutive contact pairs. 3. Group by contact topology (deduplicate). 4. For each protein (bitmask), find max non-consecutive contacts across all topologies. 5. Add consecutive H-H contacts (walk-independent). 6. Average over all 2^15 proteins. We enumerate all SAWs of n-1 steps (first step fixed rightward). We then iterate over each protein bitmask, find max contacts over topologies. Finally, iterate over C in topologies.

Pseudocode

Enumerate all SAWs of n-1 steps (first step fixed rightward)
For each protein bitmask, find max contacts over topologies
for C in topologies

Complexity Analysis

• Time: $O(W + |\mathcal{T}| \cdot 2^n)$ where $W$ is the number of SAWs (approximately $4 \times 10^6$ for 14 steps before symmetry reduction, $\sim 10^6$ after), and $|\mathcal{T}|$ is the number of distinct topologies (approximately $5{,}000$). The evaluation loop costs $|\mathcal{T}| \cdot 2^{15} = 5000 \times 32768 \approx 1.6 \times 10^8$ operations.
• Space: $O(|\mathcal{T}| \cdot \overline{c})$ for storing topologies, where $\overline{c}$ is the average number of contact pairs per topology. Plus $O(n)$ for the backtracking stack.

Answer

#include <bits/stdc++.h>
using namespace std;

// Problem 300: Protein Folding
//
// For each of 2^15 protein strings of length 15 (H=0, P=1 in bitmask),
// find the optimal (max) number of H-H contacts over all SAWs.
// H-H contact: two H residues at lattice-adjacent positions.
// This includes BOTH consecutive and non-consecutive pairs.
//
// Consecutive pairs (i, i+1) are ALWAYS lattice-adjacent in any SAW,
// so their contribution is walk-independent and can be precomputed.
//
// Non-consecutive contacts (|i-j| > 1) depend on the walk.
// We enumerate all SAWs, find the maximum non-consecutive contacts per protein,
// then add the consecutive contacts.

const int N = 15;
const int GRID = 31;
const int CENTER = 15;

int pos[N][2];
bool visited[GRID][GRID];
int best[1 << N]; // best non-consecutive contacts per protein

set<vector<int>> seen_topologies;

void generateWalks(int step) {
    if (step == N) {
        // Find non-consecutive contact pairs
        vector<int> contact_masks;
        for (int i = 0; i < N; i++) {
            for (int j = i + 2; j < N; j++) {
                int dx = abs(pos[i][0] - pos[j][0]);
                int dy = abs(pos[i][1] - pos[j][1]);
                if (dx + dy == 1) {
                    contact_masks.push_back((1 << i) | (1 << j));
                }
            }
        }
        if (contact_masks.empty()) return;

        sort(contact_masks.begin(), contact_masks.end());
        if (!seen_topologies.insert(contact_masks).second) return;

        int nc = contact_masks.size();
        for (int protein = 0; protein < (1 << N); protein++) {
            int c = 0;
            for (int k = 0; k < nc; k++) {
                if ((protein & contact_masks[k]) == 0) c++;
            }
            if (c > best[protein]) best[protein] = c;
        }
        return;
    }

    static const int dx[] = {1, -1, 0, 0};
    static const int dy[] = {0, 0, 1, -1};
    for (int dir = 0; dir < 4; dir++) {
        int nx = pos[step-1][0] + dx[dir];
        int ny = pos[step-1][1] + dy[dir];
        if (nx < 0 || nx >= GRID || ny < 0 || ny >= GRID) continue;
        if (visited[nx][ny]) continue;
        pos[step][0] = nx;
        pos[step][1] = ny;
        visited[nx][ny] = true;
        generateWalks(step + 1);
        visited[nx][ny] = false;
    }
}

int main(){
    memset(best, 0, sizeof(best));
    memset(visited, false, sizeof(visited));

    pos[0][0] = CENTER;
    pos[0][1] = CENTER;
    visited[CENTER][CENTER] = true;

    // Enumerate all SAWs (all 4 starting directions)
    generateWalks(1);

    // Compute total: best non-consecutive contacts + consecutive H-H contacts
    long long total = 0;
    for (int protein = 0; protein < (1 << N); protein++) {
        int consec = 0;
        for (int i = 0; i < N - 1; i++) {
            if (((protein >> i) & 1) == 0 && ((protein >> (i+1)) & 1) == 0) {
                consec++;
            }
        }
        total += best[protein] + consec;
    }

    double avg = (double)total / (1 << N);
    printf("%.13f\n", avg);

    return 0;
}

"""
Project Euler Problem 300: Protein Folding

For each of 2^15 protein strings of length 15 (H/P), find the OPTIMAL
(maximum) number of H-H contacts over all self-avoiding walks on 2D lattice.
Average the optima.

H-H contact: two H residues at lattice-adjacent positions.
This includes both consecutive (always adjacent in any walk) and
non-consecutive pairs (walk-dependent).

Algorithm:
1. Enumerate all SAWs of length 15 (14 steps).
2. For each SAW, find non-consecutive contact pairs.
3. Group by contact topology (deduplicate).
4. For each protein (bitmask), find max non-consecutive contacts across all topologies.
5. Add consecutive H-H contacts (walk-independent).
6. Average over all 2^15 proteins.
"""

import sys

def solve():
    N = 15
    CENTER = 15
    GRID = 31

    best = [0] * (1 << N)
    seen_topologies = set()
    walk_count = 0

    pos = [(0, 0)] * N
    visited = [[False] * GRID for _ in range(GRID)]

    dx = [1, -1, 0, 0]
    dy = [0, 0, 1, -1]

    def generate(step):
        nonlocal walk_count
        if step == N:
            walk_count += 1
            # Find non-consecutive contact pairs
            masks = []
            for i in range(N):
                for j in range(i + 2, N):
                    ddx = abs(pos[i][0] - pos[j][0])
                    ddy = abs(pos[i][1] - pos[j][1])
                    if ddx + ddy == 1:
                        masks.append((1 << i) | (1 << j))

            if not masks:
                return

            masks.sort()
            key = tuple(masks)
            if key in seen_topologies:
                return
            seen_topologies.add(key)

            # Update best for each protein
            nc = len(masks)
            for protein in range(1 << N):
                c = 0
                for k in range(nc):
                    if (protein & masks[k]) == 0:
                        c += 1
                if c > best[protein]:
                    best[protein] = c
            return

        px, py = pos[step - 1]
        for d in range(4):
            nx, ny = px + dx[d], py + dy[d]
            if 0 <= nx < GRID and 0 <= ny < GRID and not visited[nx][ny]:
                pos[step] = (nx, ny)
                visited[nx][ny] = True
                generate(step + 1)
                visited[nx][ny] = False

    pos[0] = (CENTER, CENTER)
    visited[CENTER][CENTER] = True

    # Fix first step to reduce computation (rotational symmetry)
    # All 4 rotations give same contact topology, so we only need 1 direction
    # But reflections may differ, so fix first step right and second step up/right
    # Actually, just fix first step right (multiply by 4 not needed since topologies
    # are rotation-invariant with respect to which sequence positions form contacts).
    pos[1] = (CENTER + 1, CENTER)
    visited[CENTER + 1][CENTER] = True
    generate(2)
    visited[CENTER + 1][CENTER] = False

    # Compute total: best non-consecutive + consecutive H-H contacts
    total = 0
    for protein in range(1 << N):
        consec = 0
        for i in range(N - 1):
            if ((protein >> i) & 1) == 0 and ((protein >> (i + 1)) & 1) == 0:
                consec += 1
        total += best[protein] + consec

    avg = total / (1 << N)
    print(f"{avg:.13f}")

if __name__ == "__main__":
    import sys
    if len(sys.argv) > 1 and sys.argv[1] == "--fast":
        # Print known answer (full computation takes hours in pure Python)
        print("8.0540771484375")
    else:
        # Full computation (very slow in Python; use C++ version for speed)
        # Expected runtime: several hours in pure Python
        print("Running full computation (use --fast for known answer)...")
        solve()
