Problem 155: Counting Capacitor Circuits

Mathematical Foundation

Theorem 1 (Recursive Construction). Let $D(n)$ be the set of distinct capacitance values achievable with exactly $n$ unit capacitors. Then $D(1) = \{1\}$ and for $n \ge 2$:

Proof. Any circuit of $n \ge 2$ capacitors has a top-level structure that is either a parallel or series combination of two sub-circuits. If the sub-circuits use $k$ and $n - k$ capacitors respectively ($1 \le k \le n - 1$), then:

• Parallel: total capacitance $= a + b$.
• Series: total capacitance $= \frac{1}{1/a + 1/b} = \frac{ab}{a+b}$.

Since the combination is commutative ($a + b = b + a$ and the harmonic formula is symmetric), we restrict to $k \le n - k$, i.e., $k \le \lfloor n/2 \rfloor$, without loss of generality. Every achievable capacitance arises from some such decomposition (by structural induction on circuits), and conversely every value produced by the formula is achievable. $\square$

Theorem 2 (Rationality). Every element of $D(n)$ is a positive rational number.

Proof. By induction on $n$. Base case: $D(1) = \{1\} \subset \mathbb{Q}_{>0}$. Inductive step: if $a, b \in \mathbb{Q}_{>0}$, then $a + b \in \mathbb{Q}_{>0}$ and $ab/(a+b) \in \mathbb{Q}_{>0}$ (since $a + b > 0$). $\square$

Lemma 1 (Series-Parallel Duality). If $c \in D(n)$, then $1/c \in D(n)$.

Proof. By induction on circuit structure. Base: $1 \in D(1)$ and $1/1 = 1 \in D(1)$. Inductive step: if circuit $A$ achieves capacitance $a$ and circuit $B$ achieves $b$, then:

• Parallel of $A, B$ gives $a + b$. Replacing with series gives $ab/(a+b) = 1/(1/a + 1/b)$.
• Series of $A, B$ gives $ab/(a+b)$.

By the inductive hypothesis, circuits $A', B'$ achieving $1/a, 1/b$ exist. Series of $A', B'$ gives $\frac{(1/a)(1/b)}{1/a + 1/b} = \frac{1}{a+b}$, which is $1/(a+b)$.

Thus swapping every parallel with series and vice versa transforms $c$ to $1/c$. $\square$

Lemma 2 (Representation). Each capacitance is stored as a reduced fraction $(p, q)$ with $\gcd(p, q) = 1$ and $q > 0$. Two capacitances are equal iff their reduced fractions are identical.

Proof. The rational numbers form a field, and the reduced-fraction representation is canonical. $\square$

Editorial

S(1) = {1} S(n) = union over k=1..n//2 of { a+b, a*b/(a+b) : a in S(k), b in S(n-k) } C(n) = |S(1) union … union S(n)| Uses tuples (numerator, denominator) for speed instead of Fraction. We compute cumulative union.

Pseudocode

    D = array of sets, indexed 1..N
    D[1] = {Fraction(1, 1)}

    For n from 2 to N:
        D[n] = empty set
        For k from 1 to n/2:
            For each a in D[k]:
                For each b in D[n-k]:
                    D[n].add(a + b) // parallel
                    D[n].add(a * b / (a + b)) // series

    Compute cumulative union
    all_values = D[1] union D[2] union ... union D[N]
    Return |all_values|

Complexity Analysis

• Time: For each $n$, we iterate over $\lfloor n/2 \rfloor$ splits. For each split $(k, n-k)$, we compute $|D(k)| \times |D(n-k)|$ combinations. Let $s_n = |D(n)|$. The total work is $\sum_{n=2}^{N} \sum_{k=1}^{\lfloor n/2 \rfloor} s_k \cdot s_{n-k}$. Empirically, $s_n$ grows to several hundred thousand for $n \le 18$, making the total work on the order of $10^9$ set insertions. Each insertion into a hash set is $O(1)$ amortized.
• Space: $O\!\left(\sum_{n=1}^{N} s_n\right)$ to store all sets. For $N = 18$, this is on the order of millions of fractions.

Answer

#include <bits/stdc++.h>
using namespace std;

/*
 * Problem 155: Count distinct capacitance values using up to 18 unit capacitors.
 *
 * S(1) = {1}
 * S(n) = union over k=1..n/2 of { a+b, ab/(a+b) : a in S(k), b in S(n-k) }
 * C(n) = |S(1) union ... union S(n)|
 */

typedef pair<int, int> Frac; // (numerator, denominator), always reduced, den > 0

Frac make_frac(long long p, long long q) {
    if (q < 0) { p = -p; q = -q; }
    long long g = __gcd(abs(p), q);
    return {(int)(p / g), (int)(q / g)};
}

int main() {
    const int MAXN = 18;

    vector<set<Frac>> S(MAXN + 1);
    S[1].insert({1, 1});

    set<Frac> all_values;
    all_values.insert({1, 1});

    for (int n = 2; n <= MAXN; n++) {
        for (int k = 1; k * 2 <= n; k++) {
            int m = n - k;
            for (auto& a : S[k]) {
                for (auto& b : S[m]) {
                    // Parallel: a + b = (a.p*b.q + b.p*a.q) / (a.q*b.q)
                    long long pn = (long long)a.first * b.second + (long long)b.first * a.second;
                    long long pd = (long long)a.second * b.second;
                    S[n].insert(make_frac(pn, pd));

                    // Series: ab/(a+b) = (a.p*b.p) / (a.p*b.q + b.p*a.q)
                    long long sn = (long long)a.first * b.first;
                    long long sd = (long long)a.first * b.second + (long long)b.first * a.second;
                    S[n].insert(make_frac(sn, sd));
                }
            }
        }
        for (auto& f : S[n]) {
            all_values.insert(f);
        }
    }

    printf("%d\n", (int)all_values.size());
    return 0;
}

"""
Problem 155: Count distinct capacitance values using up to 18 unit capacitors.

S(1) = {1}
S(n) = union over k=1..n//2 of { a+b, a*b/(a+b) : a in S(k), b in S(n-k) }
C(n) = |S(1) union ... union S(n)|

Uses tuples (numerator, denominator) for speed instead of Fraction.
"""
from math import gcd

def make_frac(p, q):
    """Return reduced fraction as (p, q) with q > 0."""
    if q < 0:
        p, q = -p, -q
    g = gcd(abs(p), q)
    return (p // g, q // g)

def solve():
    MAXN = 18

    S = [set() for _ in range(MAXN + 1)]
    S[1].add((1, 1))

    all_values = {(1, 1)}

    for n in range(2, MAXN + 1):
        for k in range(1, n // 2 + 1):
            m = n - k
            for (ap, aq) in S[k]:
                for (bp, bq) in S[m]:
                    # Parallel: a + b
                    pn = ap * bq + bp * aq
                    pd = aq * bq
                    S[n].add(make_frac(pn, pd))

                    # Series: ab/(a+b)
                    sn = ap * bp
                    sd = ap * bq + bp * aq
                    S[n].add(make_frac(sn, sd))

        all_values |= S[n]
        print(f"n={n}: |S(n)|={len(S[n])}, C(n)={len(all_values)}")

    print(len(all_values))

solve()
